The Harlem eBike

MOTOR
52V BAFANG HUB Motor with 500W continuous rated power

BATTERY
52V 20AH SAMSUNG Lithium-ion Battery - UL2271 Compliant

CHARGE TIME
4-6 Hours Full Charge

WARRANTY
2 Years Complete Bike Warranty

DRIVE MODE
Cadence Sensing Pedal Assist 1:9 + Twist Throttle w. Isolator

DISPLAY
Water & Dirt Resistant LCD Colour Display w. Phone Charging

SPEED
Restricted 25 km/h Public Use

SUSPENSION
Front And Rear Suspension

GEARS
SHIMANO 7 Speed

BRAKES
Large diameter 203mm TEKTRO Hydraulic Disc Brake

WEIGHT CAPACITY
Class Leading 180 kgs Carrying Weight

CRANK
High Quality Ounce Alloy Crank

INCLUSIONS
3 Stage Light Sensing LED Headlight & Tail Light, Footpegs, Mudguards

COLOUR OPTIONS
Gloss Black / Jungle Green / Blush Pink / White Noise / Desert Sand / Sage Green

BIKE WEIGHT
38KG including battery

BOX DIMENSIONS
190cm x 26cm x 90cm  |  48KG Boxed

FREE SHIPPING AUSTRALIA WIDE

On all orders over $100. Excluding some regional or remote areas.

We offer free shipping anywhere in Australia for all orders over $100 or $10 flat rate shipping for orders under $100 – surcharges may apply to remote locations within Australia.

ADDITIONAL SURCHARGES

Whilst we do deliver to most locations within Australia, we reserve the right to adjust shipping charges accordingly or to cancel orders for low freight service areas, remote or regional locations or islands. This is subject to the discretion solely of Fatboy Bikes.

DELIVERY TIMES

Orders are dispatched during business hours. Shipping times are 2–5 business days for orders in NSW or 5–12 business days for orders outside NSW. During peak periods such as Black Friday, Christmas, New Year etc. these shipping times can vary.

FATBOY HQ PICK UP

Pick up is available for all orders within NSW from our warehouse location at 44 Meta Street, Caringbah. Please contact us prior to pick up if you wish to arrange assembly of your order in advance.

ASSEMBLY & PACKAGE SIZES

Watch our assembly video here – Our eBikes come 95% assembled, with both wheels attached inside the box. A quick 15–20 minutes assembly is required.

The bike boxes are approx 190 x 26 x 90 cm and weigh 48 kg. We do recommend a professional assembly to ensure your warranty is not void.

SHIPPING DAMAGES

If you received broken or damaged packages, please ensure to take pictures and ask the courier agent to write and sign the damage description.

In case of damage or loss of the product during shipment, the customer may be required to cooperate with the seller in completing a claim application based on the courier’s required paperwork.

RETURNS POLICY

We offer 7 day returns for online purchases only. For orders made in-store, please refer to the store’s specific return policy.

In the event of a return, the cost of return will be on the purchaser. You will be responsible for proper repacking of the product in its original packaging.

If the original packaging is not accessible, no refund will be granted. If the product is damaged during return due to improper packing, the cost of repair will be on the customer’s side.

All returns must have written consent via email from Fatboy Bike Pty Ltd before they are to be shipped back to head office and processed.

To submit a return, please email our support team at hello@fatboybikes.com.au to start the returns process.

Electrically power-assisted cycle requirements:

 An electrically power-assisted bicycle has a maximum continued rated power of 500 watts. This power output must be:

(i)    progressively reduced as the bicycle’s speed increases beyond 6km/h

(ii)   cut off when:
– the bicycle reaches a speed of 25km/h
– the rider stops pedalling and the speed exceeds 6km/h.

All Fatboy Bikes models have a maximum continuous power of 250 watts at 20km/h, or 500 watts at 25km/h with a max load of 180 kgs. In the opinion of Fatboy Bikes this is inline with EPAC legislation. Before using this EPAC, check the applicable local laws relating to your intended use of the EPAC on roads and road related areas.

The electric motor should not assist the rider when travelling more than 25km/h but does not prevent the rider travelling faster with their own pedalling or going downhill. When using your ebike on private property, the bike can be unlocked to reach up to 55-60km/h.

The Fatboy Bikes are weight rated for up to 180 kgs.
